ANT-OM10A — 5GHz 10dBi Omni-directional Antenna

Descripción

To commit itself to the wireless long distance connectivity, PLANET WireFree provides a variety of antennas, cables and other accessories for 2.4GHz and 5GHz ISM band applications where more RF gain power is required to increase the convergence of the installations in the wireless state. Key Features 360 degree Horizontal Spread and 6 degree Vertical Spread Connector: N-female Operating environment: outdoor

Especificaciones técnicas

Frequency

5500-5825MHz

Antenna Type

Omni-directional

Gain (dBi)

10

SWR

<=2.0

Beamwidth Degrees

Horizontal 360 Vertical 6

Mounting Type

Pole or wall mount

Operating Temperature

-40 ∼ 70 degrees C
