ICA-4880 — H.265+ 8MP Full Color Smart IR Dome IP Camera

Descripción

Excellently Efficient Surveillance Video with Advanced 8MP IP Camera Technology PLANET ICA-4880 PoE IP Camera offers exceptional image quality with 8-megapixel resolution and supports H.264(+) and H.265(+) video compression . The ICA-4880 brings flexibility and precision to nighttime surveillance with its dual IR and warm white LED support, enabling both Smart IR and Full Color modes. This innovative combination allows the camera to adapt effortlessly to various lighting conditions, delivering clear, detailed images in black and white or vibrant full color, depending on the environment. Perfect for maintaining top-quality monitoring around the clock, the built-in microphone enables local audio capture, making it ideal for real-time communication and enhancing security with clear sound. This feature adds an extra layer of situational awareness, ensuring that nothing goes unheard in your surveillance environment. Incorporating the 1/2.7" Progressive Scan CMOS Sensor and 40-meter Smart IR/30-meter Full Color illuminators (*The IR distance is based on the environment.), the ICA-4880 is specially designed for surveillance applications, delivering sharp images in all lighting conditions. With a durable IP67-rated metal housing and a wide operating temperature range from -20 to 60 degrees C, the ICA-4880 is perfect for semi-enclosed spaces like building entrances, offices, corridors, and public transit hubs. Its robust design ensures reliable performance in demanding environments, making it ideal for critical indoor and semi-outdoor surveillance applications. Exceptional Image Quality with WDR and 3DNR Technology The ICA-4880 PoE IP Camera is crafted for optimal performance in dynamic environments, featuring Wide Dynamic Range (WDR) at 120dB and advanced 3D Noise Reduction (3DNR) technology. These powerful image processing capabilities allow it to overcome harsh lighting and background noise, delivering crystal-clear, high-definition visuals in even the most challenging lighting conditions. This makes the ICA-4880 an ideal choice for capturing fine details and ensuring superior surveillance quality in all settings. Optimized Video Compression Technology The ICA-4880 employs the H.264(+)/H.265(+) technology to enable the camera to provide higher and more efficient image compression rates. If the same image quality level of H.264 is compared with that of H.265, the latter is able to save around 83% of bandwidth, meaning H.264(+)/H.265(+ ) offers much higher quality video for less bandwidth. Thus, it can further enhance the overall performance of its IP surveillance system. Advanced Media Management with Smart Detection The ICA-4880 supports a number of advanced features to enhance surveillance flexibility and event management capabilities. The advanced features include ROI (region of interest) , motion detection, 3 configurable regions of privacy mask to protect personal privacy, and video tampering function. It also comes with defog model and image adjustment options, newly-added anti-overexposure protection function and three white balance modes. For enhanced security, it also features Intrusion Detection (based on human and vehicle detection) and Motion Detection (based on human detection). With more user-friendly GUI interface that allows users to better monitor, the ICA-4880 supports IPv6 , QoS and IEEE 802.1x functions. Newly-added secure email for password reset and email encryption protocol now can support TLS . Flexible Installation and Power Functionality Powered from a PoE power sourcing equipment such as 802.3af/at PoE switch or 802.3af/at PoE injector over a network cable, the ICA-4880, adopting the IEEE 802.3af/at standard, does not need extra power cables and manpower, thus reducing installation costs while increasing deployment flexibility and scalability. The ICA-4880 is ONVIF compliant and interoperable with other brands in the market, making it an indisputably ideal choice for reliable and high-performance surveillance. Scheduled Power Rebooting The ICA-4880 can be scheduled to reboot at a specified time like every minute, every hour, every week or every month to reduce the chance of crash resulting from buffer overflow. Remote Access via Mobile App, Web Browser or PVMS Remote management makes you easy to set the configuration and live viewing via Mobile app, NVR, HDVR, and Web browser. Besides, the ICA-4880 provides central surveillance management capability with the adoption of its bundled PLANET Video Management Software . With the PVMS , the ICA-4880 is expandable for multi-sites management of up to 256-ch IP cameras simultaneously. Users are able to monitor the IP cameras anytime, anywhere. Water-resistant and Dust-proof Protection With a robust IP67-rated metal housing, this camera is built to withstand harsh conditions, offering reliable all-weather protection against rain and dust. Its robust design ensures dependable performance in challenging environments, making it an excellent choice for demanding indoor and semi-outdoor applications such as building entrances, office corridors, public transportation hubs, and high-traffic areas. Whether it’s facing extreme weather or heavy foot traffic, the ICA-4880 delivers consistent, high-quality surveillance where it’s needed most. Applications High Scalability for Diverse Indoor Surveillance PLANET ICA-4880 8-megapixel PoE IP cam, equipped with dual IR and warm white LEDs, delivers adaptable performance in various lighting conditions, enabling clear color footage in low light and optimal visibility in total darkness. This flexibility is ideal for indoor and semi-enclosed areas like building entrances, offices, and corridors. The ICA-4880 supports 802.3af/at PoE for power over Ethernet, simplifying installation without external power. With integrated PVMS, NVR, HDVR, and user-friendly web interfaces, this camera is the ultimate choice for reliable, high-quality indoor surveillance. Key Features Camera 1/2.7" Progressive Scan CMOS Sensor 4mm fixed with 8MP lens 0.05 lux minimum illumination at F1.6 Built-in Smart IR illuminators, effective up to 40 meters *The IR distance is based on the environment. Built-in Full Color illuminators, effective up to 30 meters Switchable Smart IR/Full Color-cut filter for Day & Night function Video and Audio Simultaneous H.264(+)/H.265(+) dual-stream video encoding Supports simultaneous two streaming capabilities. H.264(+)/H.265(+) baseline profile, main profile or high profile options Max. resolution of 3840 x 2160@20fps Supports WDR (WDR) (120dB). 3DNR to improve picture quality at low lux Built-in microphone for 3~5m record sound Image adjustment options Saturation, Brightness, Contrast, Sharpness, Mirror, Anti Flicker, Video Tampering, HLC Full Color Corridor Pattern Color/B&W (IR-CUT ) White Balance Video Adjustment Image Enhancement Defog Model OSD Settings (Text, time and date overlay, and overlay image on video) Event Detection Motion detection Video tampering Intrusion detection 3 configurable regions of privacy mask to protect personal privacy ROI (Region of Interest) Power over Ethernet Compatible with IEEE 802.3af/at Power over Ethernet PD for flexible deployment Network Configuration and Management PPPoE, IPv4 DHCP Client and IPv4 Static IP Address management Supports IPv6. PLANET DDNS and Easy DDNS, TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, PPPoE, NTP, SMTP, UDP, Qos,802.1x, P2P, Cloud ONVIF compliant for interoperability Network Time Protocol (NTP) for time synchronization Schedule power rebooting System log User management options for various authorities: Admin Operator Guest System maintenance Firmware upload/download via HTTP/HTTPS Configuration upload/download through web interface Hardware-based reset button for resetting to factory default Easy configuration and management via Windows-based software or web interface PLANET Search Tools utility and Professional Video/Central Management Software NDAA compliant Case and Installation IP67-rated metal housing with cable management bracket for rigorous environment Waterproof and dustproof designs -20 to 60 degrees C operating temperature Plug and Play installation

Especificaciones técnicas

Image Sensor

1/2.7" Progressive Scan CMOS Sensor

Lens

Focus Length: 4mm Focus Control: Fixed Lens Type: Fixed Pixels: 8MP Angle of view: Horizontal FOV: 87 degrees Vertical FOV: 46 degrees Diagonal FOV: 105 degrees

Min. Illumination

0.05 lux (color) @ F1.6 0 Lux white light, B/W: 0 Lux with IR

Illuminations

Built-in Smart IR illuminators, effective up to 40 meters Built-in Full color illuminators, effective up to 30 meters *The IR distance is based on the environment.

Effective Pixels (H x V)

3840 (H) x 2160 (V)

PoE Standard

IEEE 802.3af/at PoE PD

Video Compression

H.264/H.264+/H.265/H.265+/MJPEG

Video Resolution

Item Main Stream: Sub Stream: H.264/H.264+ H.265/H.265+ 3840 x 2160@20fps 3200 x 1800@20fps 2880 x 1620@20fps 1920 x 1080@30fps 1280 x 720@30fps 1280 x 720@30fps 720 x 480@30fps 352 x 288@30fps MJPEG 1280 x 720@30fps

Item

Main Stream: | Sub Stream:

H.264/H.264+ H.265/H.265+

3840 x 2160@20fps 3200 x 1800@20fps 2880 x 1620@20fps 1920 x 1080@30fps 1280 x 720@30fps | 1280 x 720@30fps 720 x 480@30fps 352 x 288@30fps

MJPEG

1280 x 720@30fps

Frame Rate

Up to 20~30 fps for all resolutions

Bitrate

32~16384kbps

Shutter Time

Auto: 1/3-1/100000Sec

Image Setting

Saturation, Brightness, Contrast, Sharpness, Mirror, Anti Flicker, Video Tampering, HLC Full Color Corridor Pattern Color/ B&W (IR-CUT ) White Balance Video Adjustment Image Enhancement Defog Model Distortion OSD Settings Motion detection Video Tampering Intrusion Detection 3 configurable regions of privacy mask to protect personal privacy

Streaming

Streaming over UDP, TCP, HTTP, or HTTPS Controllable frame rate Constant and variable bit rate ROI (Region of Interest)

Audio Streaming

Built-in mic (On-site sound recording, effective distance 3-5M)

Audio Compression

G.711A/G.711U/AAC

Audio Input

Built-in mic

Standards Compliance

IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3af/at Power over Ethernet

Protocol

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, PPPoE, NTP, SMTP, UDP, Qos,802.1x, P2P, Cloud

Security

User Management options for various authority levels Admin Operator Guest

Users

On-line monitoring of 7 clients at the same time

Web Brower

Microsoft IE8-11, Edge, Google Chrome, Firefox

App

Yes (Android, IOS with P2P QR code)

Language

Chinese Simplified, Chinese Traditional, English, Russian, Korean, Polish, French, Japanese, Spanish, Portuguese, Italian, Hebrew, Ukrainian, Arabic, Vietnamese, Thai, Hungarian

Application Programming Interface

ONVIF compliant

Alarm Triggering

Motion detection, video tampering and intrusion detection

Alarm Events

SMTP, FTP, Cloud (Google)

Power Requirements

12V DC, 0.7A IEEE 802.3af/at Power over Ethernet

Power Consumption

3.5W (IR on) 4.3W (White LED on)

Dimensions (Φ x H)

96.24 x 89.51 mm

Weight

470g

Reset Button

Yes

LED

IR and warm LED (120∘) : 38μ x 2pcs IR 850nm 4000K warm LED

Connector

10/100Mbps Ethernet, waterproof and dustproof RJ45 connector DC power jack

Enclosure

IP67 metal case

Regulatory Compliance

FCC Part 15 Subpart B, CE

NDAA Compliance

Yes

Operating

Temperature: -20 ~ 60 degrees C Relative Humidity: 5 ~ 95% (non-condensing)

Storage

Temperature: -20 ~ 60 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
