Optical Power Meter | SM 1310/1490/1550 | MT-7803

Descripción

Optical Power Meter | SM 1310/1490/1550 | MT-7803 Features MT-7803 fiber optic power meter supports single mode fibers with three wavelengths 1310, 1490, and 1550; and it is ideal for fiber optic network installation and maintenance. Built-in optic isolator, larger and more stable compared to desktop source. Supports SC/PC connectors LCD display with Backlight Encodes each wavelength with a unique WaveID code 3 detection modulations 270Hz, 1KHz, 2KHz Easy Operation with wavelength switch Works with DC 5v power or AA batteries User friendly Fiber Optic MT-78 Power Meters Comparison Model no. MT-7801 MT-7802 MT-7803 Wavelength 1310/1550nm±10nm 850/1300nm±10nm 1310/1490/1550nm±10nm Power Stability ±0.05dB / 1hr；±0.1dB / 8hrs output Power >-5dBm >-10dBm >-5dBm OPTIC connector SC/PC Modulation 270Hz, 1kHz,2kHz Auto power off 10 minutes (could be reset) Battery Charge Yes (when using rechargeable battery), by DC 5V power jack Low battery indication Yes Storage temperature -20~+70°C; <90%RH Operating temperature -10~+60°C; <90%RH Power source 2 x 1.5V AA batteries (not included) Dimension 165× 80 × 35mm Weight 280g package Color box Fiber Optic Test Devices | Datasheet

Especificaciones técnicas

Model no.

MT-7801 | MT-7802 | MT-7803

Wavelength

1310/1550nm±10nm | 850/1300nm±10nm | 1310/1490/1550nm±10nm

Power Stability

±0.05dB / 1hr；±0.1dB / 8hrs

output Power

>-5dBm | >-10dBm | >-5dBm

OPTIC connector

SC/PC

Modulation

270Hz, 1kHz,2kHz

Auto power off

10 minutes (could be reset)

Battery Charge

Yes (when using rechargeable battery), by DC 5V power jack

Low battery indication

Yes

Storage temperature

-20~+70°C; <90%RH

Operating temperature

-10~+60°C; <90%RH

Power source

2 x 1.5V AA batteries (not included)

Dimension

165× 80 × 35mm

Weight

280g

package

Color box
