Fiber Optic Live Identifier | MT-7901

Descripción

Fiber Optic Live Identifier | MT-7901 Features MT-7901 optical fiber identifier can perform live fiber identification and detection without no damage to fibers, MT-7901 can detect optical signals without disrupting traffic. Features Indicate the signal direction in fiber Detect a variety of optical tones,270Hz, 1kHz and 2kHz; Suitable for 0.25, 0.9, 2.0, 3.0mm fiber, and no need to replace the clamp block, more convenient than others MT-7901 Optical Fiber Identifier Specs Sensitivity 250um fiber@1550nm=-35dBm 900um fiber@1550nm=-35dBm 2.5mmmm fiber@1550nm=-30dBm Max. Input +5dBm Wave Respond 800nm~1700nm Clamp Loss <2.5db Typical Power Supply AA Alkaline Cell or Ni-Mh Cell Frequency Identify 270Hz/1KHz/2KHz Fiber Type Dia. 250um/900um/2.5mm/3mm SM fiber Sound Yes Fiber Press <100KPSI Auto Power Off Yes Fiber Optic Test Devices | Datasheet

Especificaciones técnicas

Sensitivity

250um fiber@1550nm=-35dBm 900um fiber@1550nm=-35dBm 2.5mmmm fiber@1550nm=-30dBm

Max. Input

+5dBm

Wave Respond

800nm~1700nm

Clamp Loss

<2.5db Typical

Power Supply

AA Alkaline Cell or Ni-Mh Cell

Frequency Identify

270Hz/1KHz/2KHz

Fiber Type

Dia. 250um/900um/2.5mm/3mm SM fiber

Sound

Yes

Fiber Press

<100KPSI

Auto Power Off

Yes
