EPON ONU STICK SFP
Soptos EPON ONU STICK SFPs are optical transceivers with a built-in 1G EPON ONU. They comply with IEEE802.3ah EPON standard and support CTC OAM. Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA. SOPTOs EPON ONU sticks are compatible with the Small Form Factor Multi-Sourcing Agreement (MSA) and interoperable with standard-compliant EPON OLTs. Sopto supplies OEM service and Third-Party(Cisco, Juniper, HP, Dell etc.) compatible fiber optic transceivers.
Confirma disponibilidad, instalación y entrega con un asesor.
Descripción
Soptos EPON ONU STICK SFPs are optical transceivers with a built-in 1G EPON ONU. They comply with IEEE802.3ah EPON standard and support CTC OAM. Digital diagnostics functions are available via the 2-wire serial bus specified in the SFP MSA. SOPTOs EPON ONU sticks are compatible with the Small Form Factor Multi-Sourcing Agreement (MSA) and interoperable with standard-compliant EPON OLTs. Sopto supplies OEM service and Third-Party(Cisco, Juniper, HP, Dell etc.) compatible fiber optic transceivers. Feature ● Single 3.3V power supply ● Low EMI and excellent ESD protection ● Operating Case Temperature: Standard: 0~70°C ● 1310nm FP burst mode transmitter, 1490nm PIN-TIA continuous mode receiver ● Single fiber bi-directional data links symmetric 1.25Gbps EPON ONU application with EPON MAC function ● SC/UPC receptacle SFP with EPON ONU MAC inside, "Plug-and-play" via auto-discovery and configuration Compliant ● RoHS-6 ● SFP MSA ● Class I laser safety standard IEC-60825 ● Digital diagnostic monitor interface compatible with SFF-8472 Sopto fiber optic transceiver took the first lead to pass the ISO9001 quality system, the requirements of European EC, RoHs. Applications ● Ethernet Passive Optical Networks(EPON) ● An MSA-compliant SFP that incorporates not just the optics for an ONU, but all of the electronics need as well. It is a "PON on a Stick" that an entire FTTH ONU in a slightly oversized SFP. It can be plugged into networking equipment. Allowing the data interfaces on a switch , router，PBX, etc. to be customized for different fiber environments and distance requirements Ordering Information PN Application Data Rate(Gbps) Distance Fiber Output Power (dBm) Sensitivity(dBm) Interface Temp. DDM SPT-EUS3411-SB2BD SFP ports of networking equipment 1.25/1.25 PX20 SM 0 ～ 4 -27 Simplex SC 0 to 70 ℃ D
Especificaciones técnicas
Consulta las características del producto con uno de nuestros asesores.
