Industrial Fiber Media converter
The industrial Fiber media converter, which can also be called industrial fiber switch, operating temperature-40 ℃ to + 85 ℃, support wide voltage dual power input, meet IP40 protection degree and EMC industrial grade requirements, DIN rail installation.
Confirma disponibilidad, instalación y entrega con un asesor.
Descripción
The industrial Fiber media converter, which can also be called industrial fiber switch, operating temperature-40 ℃ to + 85 ℃, support wide voltage dual power input, meet IP40 protection degree and EMC industrial grade requirements, DIN rail installation. Feature ● 1 ~ 8 x 10/100 or 10/100/1000Mbps Auto-sensing RJ45 ports ● 1 ~ 4 x SC fiber ports or SFP ports ● POE optional, Max power to15.4W under af standard, 30W under at standard to each PoE port ● 4 KV Ethernet surge protection, adapt to a harsh outdoor environment ● Support Auto MDI/MDIX ● Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard ● IEEE 802.3 100Base-T or IEEE 802.3u 1000Base-TX compliant ● A store-and-forward switching mechanism ● Operating environment temperature:-40 ° ~ 85 ℃ ● Management function optional Applications ● LAN/WAN ● Access Control Systems ● Building and Environmental Control Systems ● Ethernet Fast Ethernet application Gigabit Ethernet Application Ordering Information Part No. Fiber Port Port Rate (Mbps) Port No. RJ45 Rate (Mbps) RJ45 No. POE Management Distance (km) Power Supply Temp. SFP SPM-E(1X)T4X -PXT SFP 100 1 10/100 1~4 optional No No - External 220V AC -40~85 ℃ SPM-E2XT4X -PXT SFP 100 2 10/100 2~6 optional No No - External 220V AC -40~85 ℃ SPM-EE(1X)T4X -PXT SFP 100 1 10/100 1~4 optional PSE af No - External 220V AC -40~85 ℃ SPM-EE2XT4X -PXT SFP 100 2 10/100 2~6 optional PSE af No - External 220V AC -40~85 ℃ SPM-E(1X)T2X -PXT SFP 1000 1 10/100/1000 1~8 optional No No - External 220V AC -40~85 ℃ SPM-E2XT2X -PXT SFP 1000 2 10/100/1000 2~8 optional No No - External 220V AC -40~85 ℃ SPM-E4XT2X -PXT SFP 1000 2 10/100/1000 4~8 optional No No - External 220V AC -40~85 ℃ SPM-EE(1X)T2X -PXT SFP 1000 1 10/100/1000 1~8 optional PSE af No - External 220V AC -40~85 ℃ SPM-EE2XT2X-PXT SFP 1000 2 10/100/1000 2~8 optional PSE af No - External 220V AC -40~85 ℃ SPM-EE2XT2X -PXT SFP 1000 4 10/100/1000 4~8 optional PSE af No - External 220V AC -40~85 ℃ SPM-EM(1X)T2X -PXT SFP 1000 1 10/100/1000 1~8 optional No Yes - External 220V AC -40~85 ℃ SPM-EM2XT2X -PXT SFP 1000 2 10/100/1000 2~8 optional No Yes - External 220V AC -40~85 ℃ SPM-EM2XT2X -PXT SFP 1000 4 10/100/1000 4~8 optional No Yes - External 220V AC -40~85 ℃ SPM-EEM(1X)T2X-PXT SFP 1000 1 10/100/1000 1~8 optional PSE af Yes - External 220V AC -40~85 ℃ SPM-EEM2XT2X -PXT SFP 1000 2 10/100/1000 2~8 optional PSE af Yes - External 220V AC -40~85 ℃ SPM-EEM2XT2X -PXT SFP 1000 4 10/100/1000 4~8 optional PSE af Yes - External 220V AC -40~85 ℃ 1*9 ，SC SPM-E(1X)T4X -NXXST 1*9 SC 100 1 10/100 1~4 optional No No 20~100 optional External 220V AC -40~85 ℃ SPM-E2XT4X -NXXST 1*9 SC 100 2 10/100 2~6 optional No No 20~100 optional External 220V AC -40~85 ℃ SPM-EE(1X)T4X -NXXST 1*9 SC 100 1 10/100 1~4 optional PSE af No 20~100 optional External 220V AC -40~85 ℃ SPM-EE2XT4X-NXXST 1*9 SC 100 2 10/100 2~6 optional PSE af No 20~100 optional External 220V AC -40~85 ℃ SPM-E(1X)T2X -NXXST 1*9 SC 1000 1 10/100/1000 1~2 optional No No 20~100 optional External 220V AC -40~85 ℃ SPM-E2XT2X -NXXST 1*9 SC 1000 2 10/100/1000 2~6 optional No No 20~100 optional External 220V AC -40~85 ℃ SPM-EE(1X)T2X -NXXST 1*9 SC 1000 1 10/100/1000 1~2 optional PSE af No 20~100 optional External 220V AC -40~85 ℃ SPM-EE2XT2X -NXXST 1*9 SC 1000 2 10/100/1000 2~6 optional PSE af No 20~100 optional External 220V AC -40~85 ℃
Especificaciones técnicas
Consulta las características del producto con uno de nuestros asesores.
